9G系列割草機
9G-1.0、9G-1.5、9G-1.8、9G-2.1型割草機,主要適用于草地、灌木林地的割草作業、清理,以及地表不平整牧場的更新、改造等作業,機具機構合理、堅固耐用,適用方便,保養易行,割茬高低可調,作業性能良好,是較理想的割草、清理牧場的農業機械。
Model 9G-1.0、9G-1.5、9G-1.8、9G-2.1 rotary slasher are suitable for cleaning and slashing in bush and grassland, As well as improving uneven ranch.
The machine is scientific in design, durable in service, easy to operate and maintain, adjustable in cutting height and has excellent working performance, they are more ideal agricultural machines for grass slashing and ranch cleaning.
| 型號 Model | 9G-2.1 | 9G-1.8 | 9G-1.5 | 9G-1.0 | |
| 外型尺寸 Overall Dimensions | 長Length (mm) | 3460 | 3160 | 2850 | 2570 |
| 寬Width(mm) | 2260 | 1960 | 1660 | 1400 | |
| 高Height(mm) | 1100 | 1100 | 1100 | 1100 | |
| 重量 Weight(kg) | 620 | 442 | 335 | 253 | |
| 割幅 Cutting Width(mm) | 2100 | 1800 | 1500 | 1000 | |
| 割茬高度Cutting Height(mm)(可調) | ≤50 | ≤50 | ≤50 | ≤50 | |
| 配套動力Fitted Power(HP) | 80-120 | 45-65 | 25-50 | 18-20 | |
| 掛接方式Manner Of Linkage | 三點半式懸掛Three Point Semimounted | ||||
